LM Router101-B BACnet Router – BACnet MSTP to BACnet IP
The LM Router101-B BACnet Router efficiently connects BACnet MSTP networks to BACnet IP, ensuring seamless industrial communication. Designed for reliable and high-speed data transfer, it is perfect for modern building automation systems. Available at the best price in BD from Moxa Bangladesh, this router guarantees quality and performance for your BACnet applications.
Specification Table
| Feature | Description |
|---|---|
| Model | LM Router101-B |
| Function | BACnet MSTP to BACnet IP Router |
| BACnet Protocol | Supports BACnet/IP and BACnet MS/TP |
| MSTP Interface | RS-485, up to 76.8 kbps, 128 devices maximum |
| IP Interface | 10/100 Mbps Ethernet |
| Routing | MSTP to IP and IP to MSTP routing |
| Baud Rate | 9.6, 19.2, 38.4, 76.8 kbps selectable |
| Max MSTP Devices | 128 nodes per MSTP network |
| Power Supply | 24 VDC / 100–240 VAC (model dependent) |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -40°C to 70°C |
| Humidity | 10–95% RH non-condensing |
| Mounting | DIN rail or panel mount |
| Indicators | LED status for power, MSTP activity, IP activity |
| Dimensions | Approx. 100 x 75 x 35 mm |
| Certifications | CE, FCC, BACnet Conformance |
Description:
The LM Router101-B BACnet Router is a high-performance network device designed to seamlessly integrate BACnet MSTP and BACnet IP networks. It serves as a critical bridge for building automation systems, enabling devices on a legacy MSTP network to communicate efficiently with modern BACnet/IP networks. The router supports full BACnet protocol functionality, ensuring that all standard services are available across network types.
Equipped with an RS-485 interface, the LM Router101-B can connect up to 128 devices on an MSTP network with selectable baud rates ranging from 9.6 kbps to 76.8 kbps. Its Ethernet port provides fast 10/100 Mbps communication for BACnet/IP networks, ensuring smooth data transfer and minimal latency. The device supports bi-directional routing, meaning it can transmit MSTP messages to IP networks and vice versa without losing data integrity.
The compact design allows for flexible mounting options, including DIN rail or panel installation, making it suitable for both small and large automation setups. LED indicators provide clear visibility of device status, MSTP activity, and IP traffic, simplifying monitoring and troubleshooting. With wide operating temperature and humidity ranges, the LM Router101-B is reliable in various environmental conditions. Its compliance with CE, FCC, and BACnet standards ensures interoperability and safety in building automation systems.
Key Features
- Converts BACnet MSTP (RS-485) to BACnet IP seamlessly.
- Supports multiple BACnet devices on the same network.
- Auto-detects baud rate for MSTP networks.
- Reliable and stable communication for industrial automation.
- Compact and rugged design suitable for industrial environments.
Where it Can Be Used
- Building automation systems for HVAC, lighting, and security.
- Industrial facilities requiring integration of BACnet MSTP devices with IP networks.
- Smart buildings for energy management and monitoring.
- Any setup where legacy BACnet MSTP devices need IP network access.
Installation Step
- Connect MSTP devices to the router’s RS-485 port.
- Connect the router to the Ethernet network for BACnet IP.
- Configure IP settings via the built-in web interface.
- Set up BACnet device parameters and network options.
- Test communication between MSTP and IP devices to ensure proper operation.
User Experience
Users report simple setup and reliable operation. The router bridges MSTP devices to modern BACnet IP networks without complex configuration. Its stable performance reduces downtime and network issues. The compact design allows flexible installation in tight control panels or distributed environments, making it a popular choice for building automation engineers.
What is the price of LM Router101-B BACnet Router – BACnet MSTP to BACnet IP in Bangladesh?
The estimated price of LM Router101-B BACnet Router – BACnet MSTP to BACnet IP in Bangladesh is 0৳. You can buy the LM Router101-B BACnet Router – BACnet MSTP to BACnet IP at best price from our website or visit our Office.
For the most accurate pricing, stock availability, and warranty details, we recommend contacting us before placing your order.
