MOXA EDS-2008-ELP Unmanaged Ethernet Switch
The MOXA EDS-2008-ELP is a compact unmanaged industrial Ethernet switch designed for stable and reliable communication in harsh environments. It features eight fast Ethernet ports, ensuring seamless connectivity for factory automation, IIoT, and industrial control systems. With its rugged design, fanless operation, and easy DIN-rail installation, the MOXA EDS-2008-ELP is an ideal solution for industries in Bangladesh requiring dependable and cost-effective network expansion. Moxa Bangladesh ensures authentic products, competitive pricing, and complete support for all industrial networking requirements.
Specification Table
| Feature | Details |
|---|---|
| Ports | 8 × 10/100BaseT(X) (RJ45) |
| Housing | Plastic, IP40-rated |
| Power Input | 12/24/48 VDC (operating voltage: 9.6–60 VDC) |
| Mounting | DIN-rail (wall-mountable with optional kit) |
| Operating Temperature | -10 to 60°C |
| Switching Type | Store and Forward |
| MAC Table Size | 2,000 entries |
| Packet Buffer Size | 768 Kbits |
| QoS & BSP | Configurable via DIP switches (Quality of Service, Broadcast Storm Protection) |
| EMI/EMC Compliance | High-level capabilities (EMI/EMC) |
| PROFINET Compliance | Conformance Class A (CC-A) (for hardware version 2.0.0 or later) |
| Weight | 110.5 g |
| Certifications | UL 61010-2-201, EN 62368-1, EN 55032/35, EN 61000-6-2/-6-4, CISPR 22/32, FCC Part 15B Class A, IEC 61000-4 series |
Moxa EDS-2008-ELP Description
The Moxa EDS-2008-ELP is an industrial-grade unmanaged Ethernet switch designed for reliable and cost-effective networking in harsh environments. Featuring eight 10/100BaseT(X) ports, it offers plug-and-play connectivity without the need for configuration. The switch is housed in a compact, IP40-rated plastic enclosure, ensuring protection against dust and solid objects.
Power is supplied via a 12/24/48 VDC input, with an operating voltage range of 9.6–60 VDC, making it versatile for various industrial applications. The device supports DIN-rail mounting, facilitating easy installation in control cabinets.
To enhance network performance, the EDS-2008-ELP includes Quality of Service (QoS) and Broadcast Storm Protection (BSP), both configurable through DIP switches. These features help prioritize critical data and mitigate network congestion.
The switch operates within a temperature range of -10 to 60°C, suitable for most industrial settings. It also complies with PROFINET Conformance Class A (CC-A) for models with hardware version 2.0.0 or later, ensuring compatibility with PROFINET networks.
Overall, the Moxa EDS-2008-ELP is an ideal solution for industrial Ethernet connectivity, offering reliability, ease of installation, and essential network management features.
Key Features
- Unmanaged Switch: Plug-and-play operation, no configuration needed.
- 8 Fast Ethernet Ports: Provides reliable 10/100 Mbps connections.
- Industrial-Grade Design: Rugged metal housing for harsh environments.
- Wide Operating Temperature: -40°C to 75°C suitable for industrial applications.
- DIN-Rail Mountable: Easy installation in industrial cabinets.
- Redundant Power Inputs: Enhances reliability and uptime.
- High EMC Protection: Resistant to electrical noise in industrial areas.
Where it Can Be Used
- Factory Automation: Connects sensors, PLCs, and controllers on the shop floor.
- Transportation Systems: Ideal for railways, buses, and other transport networks.
- Power and Energy Plants: Can withstand high electromagnetic interference environments.
- Surveillance Systems: Connects IP cameras in indoor/outdoor industrial setups.
- Harsh Industrial Environments: Chemical plants, oil rigs, and manufacturing floors.
Installation Step
- Mount the Switch: Use DIN-rail or wall mounting as preferred.
- Connect Power: Plug in the redundant power inputs (24–48VDC).
- Connect Devices: Plug Ethernet cables into the 8 ports.
- Verify LEDs: Ensure power and link/activity LEDs are properly lit.
- Start Operation: No additional configuration is required; the network is ready.
User Experience
- Plug-and-Play: Users report immediate connectivity without configuration hassles.
- Reliable Performance: Maintains stable communication even in high-vibration, high-temperature environments.
- Low Maintenance: Industrial-grade construction reduces the need for frequent checks.
- Flexible Deployment: Easy to install in tight spaces using DIN-rail or wall mounts.
Get in Touch with Moxa Bangladesh Industrial
- 📞 Call/WhatsApp: 01748173213
- ✉ Email: sales@datacomtechbd.com | datacomtechnologiesbd@gmail.com
What is the price of MOXA EDS-2008-ELP Unmanaged Ethernet Switch in Bangladesh?
The estimated price of MOXA EDS-2008-ELP Unmanaged Ethernet Switch in Bangladesh is 0৳. You can buy the MOXA EDS-2008-ELP Unmanaged Ethernet Switch at best price from our website or visit our Office.
For the most accurate pricing, stock availability, and warranty details, we recommend contacting us before placing your order.
