MOXA EDS-G512E-4GSFP-T Managed PoE+ Ethernet Switch
The MOXA EDS-G512E-4GSFP-T is a high-performance Managed PoE+ Ethernet Switch designed for industrial networking applications. It provides reliable Gigabit connectivity with 4 SFP slots and robust PoE+ support for powering devices directly. Ideal for seamless industrial automation and network expansion in Bangladesh.
Specification Table
| Feature | Specification |
|---|---|
| Ports – RJ45 | 8 × 10/100/1000BaseT(X) with auto-negotiation, full/half duplex, Auto MDI/MDI-X |
| Ports – SFP | 4 × 100/1000Base SFP slots |
| Alarm contact | 1 relay output, 1 A @ 24 VDC |
| Digital input | 1 channel; +13 to +30 V for “1”, −30 to +3 V for “0”, max input current 8 mA |
| Management / features | Layer-2 managed: VLAN, IGMP v1/v2/v3, GMRP, GVRP, LLDP, IPv4/IPv6, SNMP v1/v2c/v3, RMON, port mirror |
| Redundancy protocols | Link Aggregation, STP/RSTP/MSTP, Turbo Ring/Turbo Chain (millisecond-level recovery) |
| MAC table size | 8 K entries |
| Jumbo frame size | 9.6 KB |
| Packet buffer size | 4 Mbits |
| Operating voltage | 9.6 to 60 VDC (12/24/48/−48 VDC supported) |
| Input current | 0.34 A @ 24 VDC typical |
| Operating temperature | −40 °C to 75 °C |
| Storage temperature | −40 °C to 85 °C |
| Humidity | 5% to 95% non-condensing |
| Dimensions | 79.2 × 135 × 137 mm |
| Housing / Ingress rating | Metal housing, IP30 |
| Certifications | UL 508, FCC Part 15B Class A EMC, IEC 61000-4 (ESD, surge, EFT), ATEX/Division 2, EN 50121-4, NEMA TS2 |
| MTBF | ~803,337 hours |
| Warranty | 5 years |
Description:
The MOXA EDS-G512E-4GSFP-T is a rugged, industrial-grade 12-port managed Ethernet switch designed for critical network applications in harsh environments. It provides 8 copper RJ45 ports and 4 fiber SFP ports, offering flexible deployment for both short-range and long-distance network connections. With advanced Layer-2 management features like VLANs, IGMP snooping, port mirroring, and link aggregation, it ensures efficient traffic management and high network performance. Redundancy protocols such as Turbo Ring, Turbo Chain, and STP/RSTP/MSTP allow millisecond-level recovery in case of network failure, making it ideal for automation, traffic control, and industrial monitoring systems. The switch supports wide-range DC power input (9.6–60 VDC) and operates reliably from −40 °C to 75 °C, ensuring continuous operation in extreme temperatures. Its metal IP30 housing, security features, and industrial certifications make it a dependable choice for mission-critical environments. The EDS-G512E-4GSFP-T combines high reliability, flexible connectivity, and strong network management, providing a stable, high-performance backbone for industrial Ethernet networks.
Key Features
- 12-port full Gigabit managed switch: 8 × 10/100/1000BaseT(X) RJ-45 ports + 4 × 100/1000Base SFP fibre slots.
- Industrial-grade performance: Operating temperature from ‑40 °C to +75 °C for use in harsh environments.
- Managed Ethernet features: Supports VLANs (IEEE 802.1Q), IGMP v1/v2/v3 snooping, GARP/GVRP, port-mirroring, link aggregation, redundancy protocols (RSTP/STP/MSTP, Turbo Ring/Turbo Chain) for high availability.
- Security & management: HTTPS/SSL, SSH, TACACS+, RADIUS, IEEE 802.1X, MAC ACL, sticky MAC; IPv4 & IPv6 ready; SNMP v1/v2c/v3 for network monitoring.
- Industrial interfaces: Relay alarm output, digital input channel, dual power inputs (12/24/48/-48 V DC), reverse-polarity protection, overload protection.
- Rugged hardware: Metal housing (IP30), DIN-rail mounted (also wall-mountable), compact dimensions (79.2 × 135 × 137 mm) and weight ~1.44 kg.
- Certifications & reliability: Suited to demanding applications with relevant EMI/EMS/rail/industrial certifications and MTBF of ~803,000 hrs.
Where It Can Be Used
The EDS-G512E-4GSFP-T is ideal for several industrial networking scenarios:
- Factory automation & manufacturing plants: Connecting Ethernet-enabled sensors, PLCs, cameras, and building a resilient network backbone.
- Transportation systems: Train or metro networks, road-traffic control, signalling networks.
- Infrastructure & utilities: Power substations, energy, water-treatment, and remote sites where reliability and environmental tolerance matter.
- Surveillance and security: High-bandwidth links for IP cameras using SFP fibre segments, VLAN/PoE management, and video traffic optimization.
- Campus or industrial site backbone: Fibre uplinks/trunks between buildings or network segments.
Installation Steps
- Unpack & Inspect: Verify all items and check for physical damage.
- Mounting: DIN-rail or wall-mount in a suitable cabinet with adequate ventilation.
- Power Supply Connection: Connect DC power (9.6–60 V DC) to the terminal blocks. Observe polarity and dual input for redundancy.
- Network Cabling: Connect RJ-45 devices to copper ports, SFP modules to fibre slots.
- Initial Configuration: Set management IP, subnet mask, default gateway; enable SSH/HTTPS and change default credentials.
- Deploy Network Features: Configure VLANs, link aggregation, redundant topology, IGMP snooping, and port-security features.
- Test & Validate: Check connectivity, monitor LED indicators, and verify network traffic.
- Maintenance Planning: Backup configurations, monitor environment, and update firmware periodically.
User Experience
- Reliability: Stable operation in extreme temperatures due to industrial-grade build.
- Management Interface: Full suite of managed features allows fine-grained network control.
- Ease of Integration: Auto-negotiation ports, dual-power support, and DIN-rail mounting simplify installation.
- Scalability: 4 SFP slots enable fibre uplinks and remote network segments.
- Peace of Mind: Wide temperature range and rugged certifications minimize maintenance.
- Cost-effectiveness: Higher upfront cost is offset by reliability, lifespan, and advanced features.
Get in Touch with Moxa Bangladesh Industrial
- 📞 Call/WhatsApp: 01748173213
- ✉ Email: sales@datacomtechbd.com | datacomtechnologiesbd@gmail.com
What is the price of MOXA EDS-G512E-4GSFP-T Managed PoE+ Ethernet Switch in Bangladesh?
The estimated price of MOXA EDS-G512E-4GSFP-T Managed PoE+ Ethernet Switch in Bangladesh is 0৳. You can buy the MOXA EDS-G512E-4GSFP-T Managed PoE+ Ethernet Switch at best price from our website or visit our Office.
For the most accurate pricing, stock availability, and warranty details, we recommend contacting us before placing your order.
