MOXA ioLogik E2214 Active Ethernet Digital I/O Module
The MOXA ioLogik E2214 is a high-performance active Ethernet digital I/O module designed for seamless industrial automation applications. It provides reliable remote I/O control with multiple digital input and output channels. Perfect for factories, process control, and industrial monitoring, it ensures efficient and secure operation at the best price in Bangladesh.
Specification Table
| Category | Specification |
|---|---|
| Digital Inputs | 6 channels |
| Digital Input Sensor Type | Dry contact or wet contact (PNP or NPN) |
| Digital Input I/O Mode | DI or event counter (up to 900 Hz) |
| Relay Outputs | 6 channels, Form‑A (N.O.) power relays |
| Relay Contact Ratings | Inductive load: 2 A @ 30 VDC / 250 VAC / 110 VAC; Resistive load: 5 A @ 30 VDC / 250 VAC / 110 VAC |
| Ethernet Interface | 10/100 BaseT(X) via RJ‑45 (1 port) with 1.5 kV magnetic isolation |
| Serial Interface | RS‑485 (2‑wire) port, baudrates 1200–115200 bps, Modbus RTU supported |
| Power Input | 12 to 36 VDC nominal |
| Power Consumption | 170 mA @ 24 VDC (typical) |
| Operating Temperature | –10 °C to 60 °C |
| Storage Temperature | –40 °C to 85 °C |
| Dimensions | 115 × 79 × 45.6 mm |
| Weight | 250 g |
| Mounting | DIN‑rail or wall‑mounting |
| Certifications / Standards | UL 508; EMC per EN 61000‑6‑2/‑6‑4; IEC 61000‑4‑2/‑6/‑8 etc. |
| Additional Features | Click&Go logic engine (up to 24 rules), peer‑to‑peer I/O, SNMP v1/v2c/v3 support |
Description:
The MOXA ioLogik E2214 is an advanced, Ethernet‑connected remote I/O module designed for industrial automation and control applications. It features 6 digital input channels and 6 relay output channels, making it ideal for monitoring binary signals (such as dry or wet contacts) and controlling power loads via Form‑A relays. With its built‑in Click&Go logic engine, the device can be configured to execute conditional rules locally—such as triggering a relay and sending an alert when a digital input meets a threshold—without a dedicated PLC.
Its active Ethernet architecture supports event‑driven messaging (TCP/UDP, SNMP traps, email) instead of relying on constant polling, reducing network load and improving response time. Peer‑to‑peer I/O capability allows two modules to communicate directly over Ethernet with low latency. The module supports standard industrial protocols (Modbus TCP, SNMP, HTTP) and includes a built‑in RS‑485 port for serial communication or cascading additional I/O modules. Rugged and compact, it operates reliably in challenging industrial environments (–10 °C to 60 °C) and mounts easily on DIN‑rail or walls. With a compact footprint, ample I/O, robust networking, and local logic capability, the ioLogik E2214 is well suited for building automation, monitoring, telemetry, and control systems.
Key Features
- 16 Digital Inputs and 16 Digital Outputs: Provides flexible digital I/O control for industrial automation.
- Active Ethernet Technology: Ensures reliable and high-speed Ethernet communication without the need for a gateway.
- Wide Operating Temperature Range: Supports -40 to 75°C, ideal for harsh industrial environments.
- LED Indicators: Simplifies system monitoring with status indicators for power, communication, and I/O signals.
- Compact and Rugged Design: DIN-rail mountable with durable casing suitable for factory floors.
- Protocol Support: Compatible with Modbus/TCP, SNMP, and other standard industrial protocols.
- High Isolation Protection: Ensures system safety and prevents electrical damage.
Where it Can Be Used?
- Industrial Automation Systems: Monitoring and controlling machinery and processes.
- Factory Monitoring: Collecting data from sensors, switches, and actuators.
- Remote I/O Applications: Extending digital I/O access to remote locations via Ethernet.
- Building Automation: Controlling HVAC, lighting, and security systems.
- Energy Management: Integrating with smart meters and energy monitoring systems.
Installation Steps
- Mounting: Attach the ioLogik E2214 to a DIN rail or secure in an enclosure.
- Power Connection: Connect to a suitable 12–48V DC power supply.
- Ethernet Setup: Connect the module to your Ethernet network using a standard RJ45 cable.
- I/O Wiring: Connect digital input and output devices following the wiring diagram.
- Configuration: Use Moxa software or a web-based interface to configure IP addresses, I/O mapping, and protocols.
- Testing: Verify LED indicators and test inputs/outputs to ensure proper operation.
User Experience
The MOXA ioLogik E2214 offers a seamless and reliable experience for industrial users. Its active Ethernet support simplifies integration with existing networks, while robust isolation and rugged construction guarantee long-term durability in demanding environments. Users appreciate its easy DIN-rail installation, clear LED indicators, and straightforward software configuration, which reduces setup time and operational downtime. Whether deployed for remote monitoring, automation control, or energy management, the ioLogik E2214 delivers consistent, high-speed performance, making it a trusted choice for industrial professionals.
What is the price of MOXA ioLogik E2214 Active Ethernet Digital I/O Module in Bangladesh?
The estimated price of MOXA ioLogik E2214 Active Ethernet Digital I/O Module in Bangladesh is 0৳. You can buy the MOXA ioLogik E2214 Active Ethernet Digital I/O Module at best price from our website or visit our Office.
For the most accurate pricing, stock availability, and warranty details, we recommend contacting us before placing your order.
