Moxa MGate 5216 2-port Serial/Modbus-to-EtherCAT Gateway
The Moxa MGate 5216 is a high-performance Serial/Modbus-to-EtherCAT gateway built for reliable industrial automation integration. It enables seamless communication between Modbus devices and EtherCAT networks. Designed for stability and efficiency, this gateway is ideal for factories, control systems, and machine automation. Buy the Moxa MGate 5216 at the best price in BD from Moxa Bangladesh, ensuring trusted quality and fast support.
Specification Table
| Feature | Details |
|---|---|
| Model | MGate 5216 |
| Ports | 2 x DB9 male (RS-232/422/485) |
| Ethernet Ports | 2 x 10/100BaseT(X) (RJ45) with Auto MDI/MDI-X |
| EtherCAT Protocol | EtherCAT Slave |
| Modbus Protocol | Modbus RTU/ASCII Client (Master) |
| MicroPython Support | Yes (Version 1.20.0) |
| Data Size | 512 bytes input/output per port |
| Serial Isolation | 2 kV built-in |
| Baud Rate | 50 bps to 921.6 kbps |
| Flow Control | RTS/CTS, RTS Toggle (RS-232 only) |
| Power Input | Dual DC 12–48 V with redundancy |
| Relay Output | 1 x Form A (NO) relay |
| Operating Temperature | 0 to 60°C |
| Mounting | DIN-rail |
| Security Features | IEC 62443-4-2 compliant, HTTPS, SNMP, NTP |
| Dimensions (W x H x D) | 45 x 130 x 100 mm |
| Weight | Approximately 0.5 kg |
Description:
The Moxa MGate 5216 is a versatile industrial gateway designed to bridge Modbus RTU/ASCII and proprietary serial protocols with EtherCAT networks. This device enables seamless communication between serial-based devices and EtherCAT systems, facilitating integration in factory automation and semiconductor applications.
Equipped with two RS-232/422/485 serial ports, the MGate 5216 supports Modbus RTU/ASCII client (master) functionality, allowing it to manage up to 128 commands per port. It also features MicroPython support, enabling custom scripting for proprietary serial protocols. The gateway offers 512 bytes of input and output data per port, ensuring efficient data handling.
Designed for industrial environments, the MGate 5216 boasts a rugged metal housing, DIN-rail mounting, and 2 kV isolation protection on serial ports. Its dual DC power inputs enhance reliability, while the built-in relay output provides additional control capabilities. The device operates within a temperature range of 0 to 60°C, making it suitable for various industrial settings.
For ease of configuration and maintenance, the MGate 5216 includes a user-friendly web console supporting HTTPS, SNMP, and NTP. It also offers protocol diagnostics and traffic monitoring tools, simplifying troubleshooting during installation and operation.
Key Features
- Provides 2 serial ports for Modbus-to-EtherCAT conversion.
- Supports Modbus RTU/ASCII/TCP protocols.
- EtherCAT master functionality for seamless integration.
- High-speed and reliable data transmission.
- Supports multiple baud rates and flexible network settings.
- Built-in diagnostics for easy troubleshooting.
Where it Can Be Used?
- Industrial automation systems requiring communication between Modbus devices and EtherCAT networks.
- Manufacturing plants for process control and monitoring.
- SCADA systems integrating legacy Modbus equipment with modern EtherCAT controllers.
- Any environment where real-time data exchange between serial Modbus devices and EtherCAT is needed.
Installation Step
- Mount the gateway on a DIN rail or flat surface.
- Connect the serial devices to the RS-232/422/485 ports.
- Connect the EtherCAT network cable to the gateway.
- Configure the device using Moxa’s software or web console.
- Verify connections and test data communication between Modbus and EtherCAT devices.
User Experience
- Easy setup and configuration with intuitive software interface.
- Stable and reliable communication between legacy and modern industrial devices.
- Reduces downtime with clear diagnostics and monitoring tools.
- Compact design fits easily in control cabinets, saving space.
- Enhances operational efficiency by enabling seamless integration across protocols.
What is the price of Moxa MGate 5216 2-port Serial/Modbus-to-EtherCAT Gateway in Bangladesh?
The estimated price of Moxa MGate 5216 2-port Serial/Modbus-to-EtherCAT Gateway in Bangladesh is 0৳. You can buy the Moxa MGate 5216 2-port Serial/Modbus-to-EtherCAT Gateway at best price from our website or visit our Office.
For the most accurate pricing, stock availability, and warranty details, we recommend contacting us before placing your order.
