MOXA NPort 5150A Serial Device Server
The MOXA NPort 5150A Serial Device Server is a robust solution for connecting serial devices to Ethernet networks, enabling seamless industrial communication. It ensures high-speed, reliable data transfer and supports multiple operating systems for easy integration. Available at the best price in BD, it is ideal for industrial automation and networking applications in Bangladesh.
Specification Table
| Feature | Specification |
|---|---|
| Model | NPort 5150A |
| Serial Interface | 1 port RS-232/422/485 |
| Serial Data Rate | 50 bps to 921.6 kbps |
| Serial Signals | RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND RS-422/485: Tx+/-, Rx+/-, GND |
| Connector | DB9 male |
| Ethernet Interface | 1 x 10/100 Mbps RJ45 |
| Ethernet Protocols | TCP/IP, UDP, ICMP, DHCP, BOOTP, ARP, HTTP, Telnet, SNMP |
| Operating Temperature | 0 to 55°C (32 to 131°F) |
| Storage Temperature | -20 to 75°C (-4 to 167°F) |
| Humidity | 5 to 95% non-condensing |
| Power Input | 12 to 48 VDC |
| Power Consumption | 2.64 W |
| Mounting | DIN-rail or wall mount |
| Dimensions (W x H x D) | 30 x 105 x 81 mm |
| Weight | 180 g |
| Certifications | FCC, CE, UL |
| Special Features | Web console management, serial device management software, auto MDI/MDI-X |
Description:
The MOXA NPort 5150A is a high-performance serial device server designed to connect serial devices to an Ethernet network, enabling remote access and management. It supports one serial port with RS-232/422/485 interfaces, providing flexible connectivity for various industrial devices such as PLCs, sensors, and meters. With a wide serial data rate range from 50 bps to 921.6 kbps, it accommodates both slow and fast communication devices.
The device features a 10/100 Mbps Ethernet port for reliable network connectivity and supports standard TCP/IP protocols, ensuring seamless integration into existing network infrastructures. Its compact design allows for easy DIN-rail or wall mounting, making it ideal for space-constrained industrial environments. The NPort 5150A operates in a wide temperature range of 0 to 55°C and can handle humid environments, ensuring durability in demanding conditions.
Management is simplified through a web console and NPort Administrator software, providing easy setup, monitoring, and troubleshooting. Additionally, it supports security features such as SSL encryption and user authentication, enhancing network safety. With certifications including FCC, CE, and UL, the NPort 5150A meets international industrial standards. This versatile device is perfect for applications that require reliable serial-to-Ethernet conversion for industrial automation, remote monitoring, and IoT deployments.
Key Features
- Provides a reliable solution for connecting serial devices to Ethernet networks.
- Supports RS-232/422/485 serial communication for industrial equipment.
- Compatible with multiple operating systems including Windows, Linux, and Mac.
- Features TCP/IP, UDP, and serial tunneling for flexible network integration.
- Built-in web console for easy configuration and management.
- Offers secure access with SSL/TLS encryption and password protection.
- Supports both IPv4 and IPv6 networks.
- Provides automatic IP assignment via DHCP and static IP support.
Where it Can Be Used
- Industrial automation systems to connect PLCs, sensors, and HMIs.
- Factory floor monitoring and control systems.
- Remote data acquisition for SCADA systems.
- Integration of legacy serial equipment into modern Ethernet networks.
- Transportation, energy, and utility monitoring systems.
Installation Step
- Connect the serial device to the NPort 5150A using the appropriate RS-232/422/485 port.
- Connect the NPort 5150A to the Ethernet network via the RJ45 port.
- Power on the device using the provided DC power supply.
- Configure network settings using the web console or NPort Administrator software.
- Set serial parameters to match the connected device (baud rate, parity, data bits, stop bits).
- Test connectivity by sending data between the serial device and the network.
What is the price of MOXA NPort 5150A Serial Device Server in Bangladesh?
The estimated price of MOXA NPort 5150A Serial Device Server in Bangladesh is 0৳. You can buy the MOXA NPort 5150A Serial Device Server at best price from our website or visit our Office.
For the most accurate pricing, stock availability, and warranty details, we recommend contacting us before placing your order.
