Moxa TAP-323 Wi-Fi 4 Wireless Access Point
The Moxa TAP-323 Wi-Fi 4 Wireless Access Point is designed for industrial environments, delivering reliable and high-speed wireless connectivity. Ideal for factories, warehouses, and remote monitoring, it ensures seamless network performance. Get this advanced wireless solution at the best price in Bangladesh from Moxa Bangladesh.
Specification Table
| Specification | Details |
|---|---|
| Model Name | Moxa TAP-323 |
| Device Type | Wireless Access Point / Client |
| Wi-Fi Standard | IEEE 802.11a/b/g/n (Wi-Fi 4) |
| Operating Frequency | 2.4 GHz and 5 GHz Dual Band |
| Ethernet Ports | 2 x 10/100/1000BaseT(X) (RJ45) |
| Antenna Type | 3 x RP-SMA connectors for external antennas |
| Data Rate | Up to 300 Mbps (2.4 GHz) / 300 Mbps (5 GHz) |
| Security Features | WPA/WPA2, 802.1X, RADIUS, MAC filtering |
| Power Input | 12 to 48 VDC, redundant dual power inputs |
| Power Consumption | < 12 W |
| Operating Temperature | -40 to 75°C |
| Protection | IP30-rated aluminum housing |
| Mounting Options | DIN-rail or wall mounting |
| Certifications | CE, FCC, EN 50121-4, UL 61010-2-201 |
| Management | Web GUI, SNMP, CLI, MXview, and SSH support |
Description:
The Moxa TAP-323 Wi-Fi 4 Wireless Access Point is an industrial-grade wireless solution designed for robust and reliable network connectivity in harsh environments. It supports dual-band 2.4 GHz and 5 GHz communication with IEEE 802.11a/b/g/n standards, ensuring stable wireless performance for mission-critical applications. Equipped with two Gigabit Ethernet ports and three external antenna connectors, the TAP-323 delivers flexible and high-speed data transfer for both access point and client modes.
Built with an IP30-rated aluminum enclosure, the TAP-323 can withstand extreme temperatures from -40 to 75°C, making it ideal for use in industrial automation, transportation, and outdoor control systems. Advanced security protocols such as WPA2 and RADIUS authentication ensure data integrity and network safety. Its user-friendly management interfaces, including web GUI and SNMP, simplify configuration and monitoring. The Moxa TAP-323 is a reliable and rugged wireless networking solution for industrial IoT environments.
Key Features
- Dual-Radio Design: Supports IEEE 802.11a/b/g/n (Wi-Fi 4) for both 2.4 GHz and 5 GHz frequency bands.
- Industrial Grade Performance: Rugged metal housing designed to operate in harsh environments with wide temperature ranges from -40 to 75°C.
- Multiple Operation Modes: Functions as an Access Point, Client, or WDS (Bridge) to suit various industrial wireless network setups.
- Fast Roaming: Ensures uninterrupted wireless connectivity for mobile devices or moving equipment.
- Strong Security: Supports WPA2/WPA3 encryption, IEEE 802.1X authentication, and MAC address filtering for secure data transmission.
- Flexible Power Options: Supports both Power-over-Ethernet (PoE) and DC power input for installation flexibility.
- Easy Management: Web-based interface and MXconfig utility for simplified setup and monitoring.
Where it Can Be Used?
The Moxa TAP-323 is ideal for industrial automation, smart transportation systems, and remote monitoring applications. It is widely used in manufacturing plants, warehouses, and outdoor facilities where reliable wireless connectivity is needed. The device can connect field devices, mobile equipment, and control units to the main network, reducing the need for extensive cabling.
Installation Step
- Mount the TAP-323 on a DIN-rail or wall using the provided brackets.
- Connect the antennas to the radio ports for optimal signal strength.
- Power the device using a PoE switch or DC input.
- Connect to the device’s web interface via Ethernet and configure network settings.
- Set operation mode (Access Point, Client, or WDS) and apply wireless parameters.
- Save and reboot to complete the setup.
User Experience
Users appreciate the TAP-323 for its consistent performance in challenging industrial environments. Its easy configuration process, stable signal coverage, and durable build quality make it a preferred choice for long-term industrial deployments. The dual-radio design ensures seamless communication and improved network efficiency, even in areas with heavy wireless interference.
What is the price of Moxa TAP-323 Wi-Fi 4 Wireless Access Point in Bangladesh?
The estimated price of Moxa TAP-323 Wi-Fi 4 Wireless Access Point in Bangladesh is 0৳. You can buy the Moxa TAP-323 Wi-Fi 4 Wireless Access Point at best price from our website or visit our Office.
For the most accurate pricing, stock availability, and warranty details, we recommend contacting us before placing your order.
