MOXA EDS-2016-ML-SS-SC-T Unmanaged Ethernet Switch
The MOXA EDS-2016-ML-SS-SC-T Unmanaged Ethernet Switch is a durable, industrial-grade networking solution designed for harsh environments. It provides reliable 16-port connectivity with robust SC fiber interfaces for long-distance data transmission. Ideal for factories, automation systems, and utility networks, this switch ensures stable performance, extended temperature support, and long-term durability. Get the MOXA EDS-2016-ML-SS-SC-T at the best Price in BD from Moxa Bangladesh with guaranteed authenticity and fast delivery.
Specification Table
| Feature | Specification |
|---|---|
| Model | EDS-2016-ML-SS-SC-T |
| Ports | 14 × 10/100BaseT(X) (RJ45), 2 × 100BaseFX (Single-mode SC) |
| Switch Type | Unmanaged |
| Processing Type | Store and Forward |
| MAC Table Size | 8,000 entries |
| Packet Buffer Size | 2 Mbits |
| Fiber Distance | Up to 80 km (depending on fiber type and wavelength) |
| Power Input | Dual 12/24/48 VDC redundant inputs |
| Operating Voltage | 9.6 to 60 VDC |
| Relay Output | 1 A @ 24 VDC |
| DIP Switch Functions | QoS, Broadcast Storm Protection, Port Break Alarm |
| Housing | IP30-rated metal |
| Mounting | DIN-rail (standard), Wall-mount (optional) |
| Operating Temperature | -40 to 75°C |
| Certifications | UL 61010-2-201, EN 62368-1, IEC 61000-4 series, EN 50121-4 |
Product Description
The Moxa EDS-2016-ML-SS-SC-T is a robust unmanaged Ethernet switch tailored for industrial applications requiring reliable connectivity in harsh environments. It features 14 10/100BaseT(X) (RJ45) ports and 2 100BaseFX single-mode SC fiber ports, offering flexible network integration options. The switch supports a wide operating temperature range of -40 to 75°C, making it suitable for outdoor and factory floor deployments.
Designed with industrial reliability in mind, the EDS-2016-ML-SS-SC-T includes dual 12/24/48 VDC redundant power inputs, ensuring continuous operation even in the event of a power failure. Its IP30-rated metal housing provides protection against dust and physical damage, while DIN-rail mounting facilitates easy installation in control cabinets.
For enhanced network management, the switch offers DIP switch-configurable features such as Quality of Service (QoS), broadcast storm protection, and port break alarm, allowing users to tailor the device to specific network requirements. With a 5-year warranty and compliance with international safety and electromagnetic compatibility standards, the EDS-2016-ML-SS-SC-T is a dependable choice for industrial Ethernet networking needs.
Key Features
- Unmanaged Ethernet Switch: Simple plug-and-play operation, no configuration required.
- 16 Fast Ethernet Ports: Ensures reliable wired connectivity for multiple devices.
- Durable Design: Rugged industrial-grade casing, ideal for harsh environments.
- Wide Operating Temperature: Supports -10°C to 60°C, suitable for industrial applications.
- High Performance: Non-blocking switching architecture ensures smooth data transmission.
- DIN Rail Mountable: Easy installation in industrial racks or control cabinets.
- Redundant Power Inputs: Enhances reliability and reduces network downtime.
Where it Can Be Used?
The MOXA EDS-2016-ML-SS-SC-T is ideal for industrial environments such as:
- Manufacturing automation systems
- Transportation networks and railway applications
- Oil and gas or energy production plants
- Water treatment and utility monitoring systems
- Factory floors with harsh or extreme temperature conditions
Installation Steps
- Mount the switch on a DIN rail or suitable surface.
- Connect the power supply to the redundant power inputs.
- Connect network devices (PCs, PLCs, cameras) to the Ethernet ports using standard Cat5e/6 cables.
- Power on the switch; the LED indicators will show port connectivity and status.
- Verify all devices are communicating properly on the network.
What is the price of MOXA EDS-2016-ML-SS-SC-T Unmanaged Ethernet Switch in Bangladesh?
The estimated price of MOXA EDS-2016-ML-SS-SC-T Unmanaged Ethernet Switch in Bangladesh is 0৳. You can buy the MOXA EDS-2016-ML-SS-SC-T Unmanaged Ethernet Switch at best price from our website or visit our Office.
For the most accurate pricing, stock availability, and warranty details, we recommend contacting us before placing your order.
