MOXA IKS-6728-4GTXSFP-HV-HV-T Gigabit Switch
The MOXA IKS-6728-4GTXSFP-HV-HV-T Gigabit Switch is a high-performance industrial-grade managed switch designed for mission-critical networking. It provides reliable data communication with 28 Gigabit ports, ensuring ultra-fast connectivity in harsh environments. Perfect for industrial automation, transportation, and power substation networks across Bangladesh.
Specification Table
| Feature | Specification |
|---|---|
| Fixed Copper Ports | 8 × 10/100 BaseT(X) RJ45 ports |
| Combo Ports | 4 × (10/100/1000 BaseT(X) or 100/1000 Base SFP) combo ports |
| Modular Slots | 2 slots for fast‑Ethernet interface modules (additional ports or fiber) |
| Redundant Power Supply | 2 isolated power supplies, 85‑264 VAC (HV version) |
| Operating Voltage | 85‑264 VAC input range |
| Operating Temperature | –40 °C to 75 °C (wide-temperature rated) |
| Switch Properties | MAC table size ~16 K entries; packet buffer ~12 Mbits; jumbo frame ~9.6 KB |
| Redundancy & Recovery | STP/RSTP/MSTP, link aggregation, Turbo Ring/Chain recovery (ms range) |
| Physical / Mounting | Rack‑mount 19″ format; IP30 rating; metal housing; dimensions ~440 × 44 × 280 mm; weight ~4.1 kg |
| Certifications & Compliance | Railway/traffic standard EN 50121‑4; EMC/EMS per industrial specifications |
Description:
The MOXA IKS‑6728A‑4GTXSFP‑HV‑HV‑T is a high-end, modular, managed industrial Ethernet switch designed for mission-critical backbone networks in harsh environments. It features eight 10/100 Mbps RJ45 ports and four combo ports that can operate as gigabit copper or fiber SFP, offering flexible connectivity for both short-range and long-distance links. Two modular slots allow future expansion for additional ports or fiber interfaces, providing adaptability for evolving network needs.
The switch is ruggedly built with dual isolated high-voltage power supply inputs, a wide operating temperature range from –40 °C to 75 °C, and an IP30-rated metal housing, making it suitable for control rooms, transportation systems, industrial automation racks, and outdoor enclosures. Full Layer‑2 management features—VLANs, QoS, IGMP snooping, link aggregation, and rapid redundancy mechanisms like Turbo Ring and Turbo Chain—ensure reliable network performance with sub-millisecond recovery. With a large MAC table, ample packet buffering, jumbo frame support, and robust protocol support, the IKS‑6728A‑4GTXSFP‑HV‑HV‑T delivers secure, high-performance, and resilient Ethernet connectivity for demanding industrial networks.
Key Features
- Modular, managed Ethernet switch designed for industrial-grade robustness.
- 8 × 10/100BaseT(X) RJ‑45 ports + 4 × combo ports (10/100/1000BaseT(X) or 100/1000Base SFP) for high bandwidth uplinks and flexibility.
- Two modular slots for fast Ethernet interface modules (e.g., 100BaseFX, 100BaseSFP) enable future expansion or adaptation to fibre-optic infrastructure.
- Wide-range AC power input (85–264 VAC) and models with isolated dual power supplies for high reliability.
- Operating temperature from ‑40 °C to +75 °C, built for harsh industrial environments.
- Robust network redundancy and management features: supports Turbo Ring and Turbo Chain (<20 ms recovery), STP/RSTP/MSTP, IGMP snooping, VLAN, QoS, LACP, port mirroring, SNMPv1/v2c/v3, HTTPS/SSH, IEEE 802.1X and TACACS+ security.
- Surge protection (1 kV or more) and industrial certifications make it suitable for outdoor or mission-critical installations.
Where It Can Be Used
- Factory automation & industrial control systems — connecting PLCs, HMIs, sensors, and machines in manufacturing plants.
- Transportation and railway networks — suitable for wide temperature ranges and surge protection requirements.
- Marine or offshore installations — for environments with extreme conditions.
- Utility & infrastructure networks (water/wastewater, power substations) — high reliability and redundancy enable continuous operations.
- Telecommunications/ISP back-haul or data-center edge switching — gigabit combo ports allow high throughput uplinks, modular slots allow flexibility.
- Campus or large commercial buildings where VLANs, QoS, and managed redundancy are needed.
Installation Steps
- Unpack & Inspect: Verify all components are included and undamaged.
- Mounting: Attach to DIN-rail or wall-mount as required, with proper ventilation.
- Power Connection: Connect dual redundant DC power inputs for stable operation.
- Device Connection: Connect devices to copper ports; use SFP ports for fibre uplinks.
- Initial Configuration: Assign management IP, configure VLANs, QoS, link aggregation, and redundancy protocols.
- Testing & Validation: Confirm LED indicators, connectivity, and network performance.
User Experience & Benefits
- Reliable uptime — industrial-grade components and redundancy reduce downtime.
- Flexible configuration — modular slots and combo ports allow copper/fibre mix and future upgrades.
- Deterministic performance — QoS, IGMP snooping, and link aggregation ensure smooth latency-sensitive applications.
- Ease of management — web GUI, CLI, SNMP, and security features simplify network administration.
- Reduced total cost of ownership (TCO) — modular design prevents frequent hardware refreshes.
- Confidence in harsh environments — rugged build and certifications ensure reliability under extreme conditions.
What is the price of MOXA IKS-6728-4GTXSFP-HV-HV-T Gigabit Switch in Bangladesh?
The estimated price of MOXA IKS-6728-4GTXSFP-HV-HV-T Gigabit Switch in Bangladesh is 0৳. You can buy the MOXA IKS-6728-4GTXSFP-HV-HV-T Gigabit Switch at best price from our website or visit our Office.
For the most accurate pricing, stock availability, and warranty details, we recommend contacting us before placing your order.
