MOXA NPORT 5650-8-DT RS232 422 485 Device Server
The MOXA NPort 5650-8-DT is a high-performance RS232/422/485 device server designed for industrial automation and serial-to-Ethernet conversion. It supports multiple serial protocols and ensures reliable communication across networks. Available now in Bangladesh at competitive prices from Moxa Bangladesh.
Specification Table
| Specification | Details |
|---|---|
| Device Type | Serial Device Server |
| Serial Ports | 8 x RS-232/422/485 |
| Serial Communication Speed | 50 bps to 921.6 kbps |
| Data Bits | 5, 6, 7, 8 |
| Stop Bits | 1, 1.5, 2 |
| Parity | None, Even, Odd, Space, Mark |
| Flow Control | None, RTS/CTS, XON/XOFF |
| Network Interface | 1 x 10/100 Mbps Ethernet port |
| IP Protocols | TCP, UDP, DHCP, BOOTP, ARP, ICMP |
| Operating Temperature | 0°C to 60°C (Standard), -40°C to 75°C (Wide Temp version) |
| Storage Temperature | -40°C to 85°C |
| Power Input | 12 to 48 VDC |
| Power Consumption | 2.5 W per port |
| Housing | Rugged metal, DIN-Rail or Wall-mount |
| Isolation | 1.5 kV serial, 1.5 kV Ethernet |
| LEDs | Power, Link/Activity, Serial TX/RX |
| Certifications | FCC Class A, CE, UL |
| Management | Web Console, Windows Utility, Telnet/SSH |
Description:
The MOXA NPort 5650-8-DT is an industrial-grade serial device server designed to connect multiple RS-232, RS-422, or RS-485 devices to an Ethernet network, enabling seamless serial-to-network communication. With eight serial ports, it allows simultaneous connections for multiple devices such as PLCs, sensors, and meters, making it ideal for automation, manufacturing, and energy management applications. The device supports high-speed serial communication up to 921.6 kbps with flexible settings for data bits, stop bits, parity, and flow control, ensuring compatibility with a wide range of industrial devices.
Equipped with a 10/100 Mbps Ethernet interface and multiple network protocols including TCP/IP, UDP, DHCP, and ARP, the NPort 5650-8-DT provides reliable, real-time data transfer across networks. Its rugged metal housing and wide operating temperature range make it suitable for harsh industrial environments. Advanced isolation protection safeguards both the serial and Ethernet ports against voltage surges, enhancing system stability. Management is easy via web console, Windows utility, or Telnet/SSH, allowing straightforward configuration and monitoring. The NPort 5650-8-DT combines durability, flexibility, and ease of integration, making it a dependable solution for extending legacy serial devices into modern networked systems without significant infrastructure changes.
Key Features
- Serial Device Connectivity: Supports 8-port RS232/422/485 serial devices.
- High-Speed Data Transfer: Offers fast data transmission up to 921.6 kbps.
- Flexible Protocols: Supports TCP/IP, UDP, HTTP, Telnet, and more.
- Advanced Security: Built-in SSL encryption, user authentication, and IP filtering.
- Industrial Reliability: Wide operating temperature (-40 to 75°C), DIN-rail mounting, and robust surge protection.
- Easy Management: Web-based, Windows utility, and command-line management tools.
- Redundant Network Support: Dual Ethernet ports with failover for network reliability.
Where it Can Be Used?
- Industrial Automation: Connect PLCs, CNC machines, sensors, and other serial equipment to an Ethernet network.
- Building Automation: Monitor and control HVAC systems, lighting, and security devices.
- Transportation Systems: Integrate serial devices in buses, trains, or traffic control networks.
- Energy Management: Remote monitoring of smart meters and power distribution equipment.
- Retail & Banking: Connect legacy POS systems and ATMs over Ethernet networks.
Installation Step
- Mount the Device: Install on a DIN rail or flat surface.
- Connect Serial Devices: Attach RS232/422/485 devices using appropriate cables.
- Connect Network: Plug Ethernet cables into the device’s ports.
- Configure Network Settings: Use web console or Windows utility to set IP address, subnet, and gateway.
- Assign Serial Parameters: Configure baud rate, parity, data bits, and stop bits per connected device.
- Test Connectivity: Verify that the serial devices communicate correctly over the network.
What is the price of MOXA NPORT 5650-8-DT RS232 422 485 Device Server in Bangladesh?
The estimated price of MOXA NPORT 5650-8-DT RS232 422 485 Device Server in Bangladesh is 0৳. You can buy the MOXA NPORT 5650-8-DT RS232 422 485 Device Server at best price from our website or visit our Office.
For the most accurate pricing, stock availability, and warranty details, we recommend contacting us before placing your order.
