Moxa OnCell 3120-LTE-1 Series Industrial Cellular Gateway
The Moxa OnCell 3120-LTE-1 Series Industrial Cellular Gateway provides secure and reliable LTE connectivity for industrial networks. Perfect for remote monitoring, IoT integration, and automation projects in Bangladesh. Designed for rugged environments, it ensures uninterrupted data communication for mission-critical applications.
Specification Table
| Feature | Details |
|---|---|
| Model | OnCell 3120-LTE-1 Series |
| Cellular Connectivity | LTE, HSPA+, UMTS, GSM/GPRS/EDGE |
| Frequency Bands | LTE: FDD B1/B3/B5/B7/B8/B20, TDD B38/B40/B41 UMTS: B1/B5/B8 GSM/GPRS/EDGE: 850/900/1800/1900 MHz |
| Ethernet Ports | 1 x 10/100 Mbps RJ45 |
| Serial Ports | 1 x RS-232/422/485 (optional) |
| Wireless Standards | LTE Cat 1, fallback to 3G/2G |
| Operating Temperature | -40°C to 75°C (-40°F to 167°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Power Input | 12–48 VDC |
| Power Consumption | 3.5 W (typical) |
| Antenna | 2 x SMA connectors for LTE/3G/2G |
| Security Features | VPN (IPSec, OpenVPN), firewall, HTTPS, SSH |
| Protocols Supported | TCP/IP, UDP, HTTP, SNMP, Modbus TCP/UDP |
| Mounting | DIN-rail or wall mount |
| Certifications | CE, FCC, UL, RoHS |
Moxa OnCell 3120-LTE-1 Series Description
The Moxa OnCell 3120-LTE-1 Series is a rugged industrial cellular gateway designed for reliable machine-to-machine (M2M) and IoT connectivity in harsh environments. Supporting LTE Cat 1 technology with backward compatibility to 3G and 2G networks, it ensures uninterrupted cellular communication for industrial applications such as remote monitoring, SCADA systems, and telemetry networks. The gateway provides a single Ethernet port for network integration and an optional RS-232/422/485 serial port for connecting legacy devices, enabling seamless communication between modern IP networks and older industrial equipment.
Engineered for extreme conditions, the OnCell 3120-LTE-1 operates reliably within a wide temperature range from -40°C to 75°C, making it suitable for outdoor, factory, or transportation deployments. Security is a priority, with built-in VPN support, firewalls, and secure remote management to protect critical data and prevent unauthorized access. With multiple mounting options including DIN-rail and wall installation, the gateway offers flexible deployment in tight or constrained spaces. Its low power consumption and versatile voltage input (12–48 VDC) further enhance its suitability for energy-conscious industrial environments.
Overall, the OnCell 3120-LTE-1 Series combines rugged design, flexible connectivity, and advanced security features, making it an ideal solution for industrial automation and remote monitoring applications requiring reliable cellular network access.
Key Features
- Reliable LTE Connectivity: Supports LTE Cat 1 for stable cellular communication.
- Industrial-Grade Design: Ruggedized casing suitable for harsh environments.
- Multiple Interfaces: Includes Ethernet ports for device connectivity and integration.
- Secure Communication: Built-in VPN and firewall for data protection.
- Remote Management: Supports easy remote monitoring and configuration.
- Flexible Power Options: Operates on wide-range DC input (9–48 VDC).
Where it Can Be Used
- Industrial Automation: Connects PLCs, sensors, and controllers to the network.
- Remote Monitoring: Ideal for oil, gas, and water utility installations.
- Transportation Systems: Provides cellular connectivity for vehicle or train applications.
- Smart City Projects: Enables IoT devices and traffic monitoring systems.
- Energy Management: Monitors solar, wind, or other distributed energy resources.
Installation Step
- Mount the gateway on a DIN rail or secure surface.
- Connect the LTE antenna to ensure strong signal reception.
- Connect Ethernet devices to the gateway’s LAN port.
- Supply power through the DC terminal.
- Configure network settings using Moxa’s OnCell Manager or web interface.
- Test connectivity and verify remote access.
User Experience
Users report that the OnCell 3120-LTE-1 provides stable cellular connections even in challenging industrial environments. Its rugged design ensures longevity, and remote management simplifies monitoring and troubleshooting. The flexible installation options and secure communication features make it a reliable choice for industrial IoT and remote monitoring applications.
What is the price of Moxa OnCell 3120-LTE-1 Series Industrial Cellular Gateway in Bangladesh?
The estimated price of Moxa OnCell 3120-LTE-1 Series Industrial Cellular Gateway in Bangladesh is 0৳. You can buy the Moxa OnCell 3120-LTE-1 Series Industrial Cellular Gateway at best price from our website or visit our Office.
For the most accurate pricing, stock availability, and warranty details, we recommend contacting us before placing your order.
